The Multicolor rotary tablet press machine produced by Rich Smart is a professional equipment that continuously presses and forms a variety of raw materials.
It is mainly used in the production of tablets in the food ,pahrmaceutical and chemical industries. Multicolor rotary tablet press machine is suitable for pressing double-layer tablets, three-color tablets, three-layer tablets and other large tablets that are difficult to form, such as milk tablets, calcium tablets, camphor balls and powder metallurgy products; it is also suitable for industrial sectors such as electronics and ceramics. The Multicolor rotary tablet press machine can press various geometric shapes of round tablets, multi-layer tablets, ring tablets, special-shaped tablets, and double-sided engraved tablets. Especially for pressing three-layer Smurf blocks, toilet cleaning fast, etc.
Feature of Multicolor rotary tablet press machine
1. The outer cover is sealed with transparent organic glass, so you can clearly view the tablet pressing, and it can be fully opened for cleaning and maintenance.
2. The part in contact with the material is made of qulitied stainless steel ,and also can be undergone special surface treatment, which is non-toxic and corrosion-resistant.
3. The surface of the turntable has been specially treated to keep it smooth and prevent cross contamination, which meets GMP requirements.
4. When pressing tablets, multi-layer optional tablets can be customized according to the sample.
5. The hydraulic system is equipped with an overload protection device, which can automatically stop if pressure is overloaded.
6. The lower enclosure is made of stainless steel, and the turntable speed is variable frequency speed regulation.
Parameter
|
Model |
RS-ZP55D |
RS-ZP51D |
RS-ZP41D |
|
Capacity |
260000pcs/h |
220000pcs/h |
160000pcs/h |
|
Applicable material |
Powder,granule |
||
|
Applicable tablet types |
round tablets, special-shaped tablets, double color and annular tablet. |
||
|
Max. pressure |
120KN |
||
|
Max. tablet diameter |
13mm |
19mm |
25mm |
|
Maximum press thickness |
8mm |
9mm |
9mm |
|
GMP requirements |
The main body adopts SS304, All the contacting parts of the tablet press meet the requirements of "no poison, no odor and corrosion prevention". |
||
|
Precision |
The hole of upper punch, lower punch and middle mold,the axis of outer circle to the center of the shaft hole coaxiality is H8 (-0.165/0). The sensitivity of the hand wheel is 0.1mm. |
||
|
Power supply |
380/220V/50Hz |
||
|
Power |
7.5kw |
||
|
Weight |
2000kg |
||
|
Outline dim. |
1220×1120×1850 mm |
||
|
Packing/size |
Standard export wooden case/1600×1300×2160mm |
||
|
Warranty |
two years |
||
|
Method of Warranty |
Remote telephone and video guidance or home service according to customer requirements |
||
|
Time of delivery |
Shipped in 15 days after payment |
||
|
Payment term |
L/C,T/T,Western Union |
||
|
Port of loading |
Guangzhou or Shanghai |
||
Application
Our factory
Our certificates
Our Exhibition
